APK23 is a high-capacity self-service card issuing kiosk designed for transit systems, public-service locations, and healthcare registration environments that require fast, reliable card dispensing.
With dual card dispensers, a 27-inch Full HD touchscreen, QR-code scanning, card-reading options, and industrial receipt printing, APK23 helps operators streamline card issuance, reduce counter queues, and improve service speed in high-traffic locations.
It is ideal for metro stations, bus terminals, transport hubs, hospital registration halls, public-service centers, and smart mobility projects.
APK23 is built for self-service workflows where card availability, transaction speed, and continuous operation matter. Its dual card dispenser configuration can hold up to 300 ISO-standard cards, supporting frequent card issuance without repeated staff intervention.
Passengers, patients, and visitors can use the large touchscreen to follow service instructions, scan a QR code, verify card details, collect a new card, and receive a printed confirmation. The freestanding cabinet gives the kiosk a clear presence in busy public spaces.
Key Specifications
27-inch IPS Full HD touchscreen
Dual card dispensers
Up to 300 ISO-standard cards
10-point projected capacitive touch
QR code and barcode scanning
NFC and contactless card-reading options
80 mm industrial thermal receipt printer option
Android 11 or Windows 10/11 options
Dimensions: 1720 × 620 × 480 mm
APK23 is a practical solution for issuing, replacing, and servicing transit cards in self-service environments. Its high-capacity card-dispensing configuration supports public transport projects where passengers need convenient access to travel cards outside staffed service windows.
With compatible software, the kiosk can support new-card issuance, card replacement, balance-related information, QR-code service flows, passenger guidance, route information, and receipt printing.
Typical Applications
Metro and subway stations
Bus terminals
Railway and transport hubs
Airport ground-transport areas
Smart mobility centers
Parking and access-management projects
Public-service card distribution
Campus transportation systems
APK23 is configured with dual card dispensers that hold up to 300 ISO-standard cards. This makes it suitable for high-frequency card-issuance projects where availability and operational continuity are essential.
The dual-dispenser design supports more efficient card handling and can be configured around your card type, issuance process, and software workflow. It is a strong hardware platform for transport cards, membership cards, access cards, public-service cards, and other compatible smart-card applications.
Card-Issuance Highlights
Dual card-dispenser configuration
Up to 300 ISO-standard cards
Designed for frequent dispensing workflows
Suitable for compatible contactless, smart-card, and transit-card projects
Freestanding enclosure for public locations
Custom hardware configuration available
APK23 can integrate key transaction and validation modules into one self-service terminal. Citizens and passengers can scan QR codes, read compatible contactless cards, and print service confirmations or receipts without moving between multiple devices.
The optional 80 mm industrial thermal printer supports high-speed output and large paper rolls, while the 2D scanner supports common QR-code and barcode formats. This flexible configuration helps operators build a smoother, more complete ticketing or card-service workflow.
Integrated Service Modules
2D QR code and barcode scanner
NFC and contactless card reader
Compatible CPU/IC card reader option
80 mm industrial thermal receipt printer
Up to 180 mm/s print speed
150 mm jumbo paper-roll configuration
1080P camera option
USB and HDMI expansion
APK23 uses a durable metal enclosure with aluminum-alloy structural components, powder coating, and hardened tempered-glass touchscreen protection. It is designed for frequent public interaction in demanding indoor transport and service environments.
The cabinet can be customized with your transport brand, public-service logo, color scheme, user-interface requirements, selected operating system, and peripheral layout.
Construction Highlights
Heavy-duty sheet-metal cabinet
Aluminum-alloy structure
Powder-coated finish
AG/AF tempered touchscreen glass
Surface hardness: ≥6H
Integrated 5W × 2 speakers
Standard color: white and black
Custom colors, logo, and modules available
AONKIOSK develops self-service kiosk hardware for high-traffic public environments. We combine enclosure engineering, card-dispensing integration, peripheral selection, prototype testing, and scalable manufacturing to help customers deploy reliable ticketing and card-service terminals.
Our card-service kiosk configurations are designed around practical dispensing workflows, helping operators provide convenient access to transit cards and other compatible cards.
Combine card dispensers, QR scanners, card readers, cameras, receipt printers, and other modules in one coordinated self-service terminal.
Heavy-duty metal enclosures, protected internal components, and hardened touchscreen glass help support frequent daily interaction in busy locations.
Customize the cabinet design, branding, operating system, card modules, peripheral layout, and connectivity around your local transit or public-service requirements.
AONKIOSK helps transport operators, system integrators, and public-service providers deploy practical self-service hardware for card issuance and customer guidance.
High-capacity card issuing
Dual card dispensers with capacity for up to 300 ISO-standard cards support continuous service in high-traffic environments.
One terminal for multiple service steps
Bring together card dispensing, QR scanning, card reading, receipt printing, and digital service guidance in one kiosk.
Designed for public transport environments
The freestanding, heavy-duty enclosure is suitable for indoor stations, transport hubs, public halls, and mobility centers.
Android and Windows platform options
Choose the system configuration that best fits your ticketing platform, software integration, management tools, and required peripherals.
Custom hardware for your project
Adapt the cabinet color, logo, card-dispensing configuration, screen interface, connectivity, and module selection for your deployment.
APK23 is a self-service transit card issuing kiosk. It is designed for projects that require card dispensing, QR scanning, card reading, receipt printing, and digital customer-service guidance.
APK23 is configured with dual card dispensers that can hold up to 300 ISO-standard cards. Final capacity may vary depending on the card type and selected dispenser configuration.
Yes. APK23 is suitable for metro stations, bus terminals, railway stations, airports, smart mobility centers, and other public transport locations where users need self-service card access.
Yes. With compatible card-dispensing hardware and software integration, APK23 can support transit-card issuance and related self-service workflows.
Yes. APK23 can include a 2D scanner that supports QR Code, PDF417, DataMatrix, UPC, EAN13, Code128, Code39, and other common code formats.
| Category | Specification |
|---|---|
| Product Model | APK23 |
| Product Type | Transit card issuing kiosk |
| Installation Type | Freestanding floor-standing kiosk |
| Display Size | 27 inches |
| Display Panel | IPS LCD |
| Display Resolution | 1920 × 1080 Full HD |
| Display Aspect Ratio | 16:9 |
| Display Area | 597.60 × 336.15 mm |
| Display Brightness | 300 cd/m², typical |
| Viewing Angle | 89° / 89° / 89° / 89°, typical |
| Contrast Ratio | 1000:1, typical |
| Refresh Rate | 60 Hz |
| Touch Technology | Projected capacitive touch |
| Touch Points | 10-point multi-touch |
| Touch Input | Finger, gloved hand, or capacitive stylus |
| Touch Accuracy | ≤2 mm |
| Touch Response Time | ≤6 ms |
| Touch Surface | AG + AF tempered glass |
| Touch Surface Hardness | ≥6H |
| Android Option | Android 11, quad-core ARM Cortex-A55, 4 GB RAM, 32 GB storage |
| Windows Option | Windows 10/11, Intel Core i5, 8 GB RAM, 128 GB or 256 GB SSD |
| Network | Wi-Fi 2.4G/5G, RJ45 Ethernet, optional 4G |
| Ethernet Port | RJ45 10/100/1000M adaptive port |
| USB Ports — Android | 1 × USB 3.0, 1 × USB 2.0, OTG expansion |
| USB Ports — Windows | 1 × USB 3.0, 2 × USB 2.0 |
| HDMI | 1 × HDMI output |
| Card Dispenser | Dual card dispensers |
| Card Capacity | Up to 300 ISO-standard cards |
| Optional Scanner | 2D QR code and barcode scanner |
| Scanner Code Types | QR Code, PDF417, DataMatrix, UPC, EAN13, Code128, Code39 |
| Optional Card Reader | NFC and contactless card reader |
| Supported Card Types | Mifare One S50/S70 and Mifare UltraLight NTAG213/215/216 |
| Optional Medical Card Reader | Compatible multi-card reader for CPU/IC card projects |
| Card Reading Distance | 0–5 cm, depending on card and module |
| Optional Camera | 1080P camera, up to 30 fps |
| Receipt Printer | 80 mm industrial thermal printer |
| Receipt Print Speed | Up to 180 mm/s |
| Receipt Print Resolution | 203 dpi |
| Receipt Print Width | 72 mm |
| Receipt Paper Roll | 150 mm jumbo roll configuration |
| Cutter | Full-cut and half-cut support with anti-jam sensor |
| Cabinet Material | Sheet metal with aluminum-alloy structure |
| Surface Finish | Powder coating |
| Screen Protection | AG/AF tempered glass |
| Speakers | 4Ω, 5W × 2 |
| Standard Cabinet Color | White and black |
| Customization | Cabinet color, logo, card modules, internal layout, and hardware configuration |
| Product Dimensions | 1720 × 620 × 480 mm |
| Net Weight | Approx. 68.12 kg |
| Gross Weight | Approx. 82.35 kg |
| Operating Temperature | -15°C to 50°C |
| Operating Humidity | 10% RH to 90% RH, non-condensing |
| Storage Temperature | -20°C to 60°C |
| Storage Humidity | 10% RH to 90% RH, non-condensing |
Specifications may vary according to card type, selected modules, software integration, and project requirements. Please confirm the final card-dispensing and card-reading configuration before production.
